Power Output per Channel:
   100 Watts into 8 Ohms
   160 Watts into 4 Ohms
Number of Channels: 2
Speaker Impedance: 4 or 8 Ohms
Rated Power Band: 20Hz to 20kHz
Total Harmonic Distortion: 0.005%
Dynamic Headroom: 1.8dB
Frequency Response:
   +0,-0.5dB: 20Hz to 20kHz
   +0, -3dB: 10Hz to 100kHz
Sensitivity:
   Phono (Moving Coil): N/A
   Phono (Moving Magnet): 2.5mV
   High Level (Balanced / Unbalanced): 0.5V/0.25V
   Power Amp input: 1V
Signal To Noise Ratio:
   Moving Coil: N/A
   Moving Magnet: 82dB
   High Level: 95dB
   Power Amp input: 110dB
Input Impedance (Balanced / Unbalanced): 20K/20K
Damping Factor: 8 Ohms: >200
4 Ohms: >100
Maximum Output (Balanced / Unbalanced): 8V Unbalanced
Headphone Output: 1/4" High Drive with Headphone Crossfeed Director (HXD)
DAC Type: 8-channel, 32-bit/192kHz PCM/DSD, Quad Balanced
Digital Coaxial Input Sample Rate: 24-bit/44.1kHz to 192kHz
Digital Optical Input Sample Rate: 24-bit/44.1kHz to 192kHz
Digital MCT (DIN) Input Sample Rate:
   16-bit/44.1kHz (CD)
   DSD64 (SACD)
Digital USB Input Sample Rate: 32-bit/44.1kHz to 384kHz (PCM)
DSD64, DSD128, DSD256, DXD352.8kHz, DXD384kHz
Tone Controls: Bass and Treble
Chassis Finish: Black painted steel
Power Requirement: 120V 50/60Hz, 2.3A
Standby Power Requirement: <0.25 Watts
Dimensions (W HD): 17.5" x 6" x 22"
Weight: 38 lbs.

McIntosh - MA5300 Integrated Amplifier

$5,900.00Price
